| Kör Tapa (Elektrofüzyon Ek Parçası) | |||
     | |||
| D | PN6 | PN10 | PN16 |
| mm | KOD.NO | KOD.NO | KOD.NO |
| Ø90MM | 1.18.006.0090.0000 | 1.18.010.0090.0000 | 1.18.016.0090.0000 |
| Ø110MM | 1.18.006.0110.0000 | 1.18.010.0110.0000 | 1.18.016.0110.0000 |
| Ø125MM | 1.18.006.0125.0000 | 1.18.010.0125.0000 | 1.18.016.0125.0000 |
| Ø140MM | 1.18.006.0140.0000 | 1.18.010.0140.0000 | 1.18.016.0140.0000 |
| Ø160MM | 1.18.006.0160.0000 | 1.18.010.0160.0000 | 1.18.016.0160.0000 |
| Ø180MM | 1.18.006.0180.0000 | 1.18.010.0180.0000 | 1.18.016.0180.0000 |
| Ø200MM | 1.18.006.0200.0000 | 1.18.010.0200.0000 | 1.18.016.0200.0000 |
| Ø225MM | 1.18.006.0225.0000 | 1.18.010.0225.0000 | 1.18.016.0225.0000 |
| Ø250MM | 1.18.006.0250.0000 | 1.18.010.0250.0000 | 1.18.016.0250.0000 |
| Ø280MM | 1.18.006.0280.0000 | 1.18.010.0280.0000 | 1.18.016.0280.0000 |
| Ø315MM | 1.18.006.0315.0000 | 1.18.010.0315.0000 | 1.18.016.0315.0000 |
| Ø355MM | 1.18.006.0355.0000 | 1.18.010.0355.0000 | 1.18.016.0355.0000 |
| PN10 Kör Tapa Fiyat Listesi | |||||
| d | Kg | D (mm) | L (mm) | Ebat | Fiyat (Euro) |
| Ø200 | 4,66 | 245 | 220 | 60/40/45 | 72 € |
| Ø225 | 6,24 | 260 | 230 | 60/40/30 | 99 € |
| Ø250 | 8,10 | 285 | 240 | 60/40/45 | 177 € |
| Ø280 | 11,20 | 325 | 240 | 60/40/45 | 227 € |
| Ø315 | 15,05 | 360 | 245 | 60/40/45 | 315 € |
| Ø355 | 15,60 | 440 | 300 | 60/40/45 | 395 € |
| Ø400 | 21,10 | 495 | 350 | – | Fiyat Sorunuz |
| Ø450 | 29,45 | 554 | 370 | – | Fiyat Sorunuz |
| Ø500 | 38,80 | 615 | 415 | – | Fiyat Sorunuz |
| Ø560 | 54,65 | 690 | 460 | – | Fiyat Sorunuz |
| Ø630 | 73,50 | 775 | 480 | – | Fiyat Sorunuz |
| Ø710 | 101,50 | 880 | 505 | – | Fiyat Sorunuz |
| PN16 Kör Tapa Fiyat Listesi | |||||
| d | Kg | D (mm) | L (mm) | Ebat | Fiyat (Euro) |
| Ø110 | 1,39 | 140 | 97 | 60/40/30 | 28 € |
| Ø160 | 2,89 | 200 | 115 | 60/40/30 | 62 € |
| Ø200 | 4,85 | 250 | 140 | 60/40/30 | 105 € |
| Ø250 | 6,10 | 315 | 170 | 60/40/30 | 212 € |
| Ø315 | 10,80 | 400 | 220 | – | 257 € |
| Ø400 | 16,90 | 500 | 230 | – | 405 € |
| Ø500 | 32,50 | 630 | 280 | – | 780 € |
| Ø560 | 42,70 | 710 | 270 | – | 1024 € |
